Audient Oria

Atmos just got easy Meet ORIA, the world's first audio interface and monitor controller designed specifically with immersive audio in mind. Built for creating immersive audio mixes for formats such as Dolby Atmos, ORIA lets you calibrate, control and monitor multi-channel speaker arrays from stereo up to 9.1.6 and everything in between. Perfect for music, film, TV, game and VR production.

A perfect fit Designed with a dual purpose, ORIA not only excels as a powerful USB-C audio interface providing 16 outputs for up to 9.1.6 mixing workflows, but can also effortlessly integrate into your existing studio setup as a standalone monitor controller via its ADAT Inputs. Flexibility where you need it.

Advanced Speaker Processing Working with multi-channel speaker setups requires a precisely calibrated room but let's face it, calibrating your room is a difficult and time consuming process. But what if it didn't have to be

All present & correct ORIA's Advanced Speaker Processing lets you calibrate your room and create custom onboard calibration Profiles (presets) for any monitoring format from stereo to surround to 9.1.6 immersive setups, making reference checking your mix in different formats a breeze.

Add to that the ability to calibrate your room in one of two ways. Either create a Profile by manually taking room measurements and dialling in the calibration settings or take advantage of upgrading to SoundID Reference...

It just Sonarworks We've teamed up with room calibration heavyweights Sonarworks to bring you a seamless integration with SoundID Reference letting you accurately measure and calibrate multi-channel setups in less than an hour.

With a SoundID Reference Microphone and 60 day free trial of SoundID Reference for Multichannel software included, ORIA lets you create custom SoundID Profiles for different monitoring formats and target modes, load them into ORIA and take advantage of consistently accurate and low latency immersive audio.

CPU Later And the best part is, ALL of ORIA's Advanced Speaker Processing, whether using manual or SoundID calibrations, runs directly off its lightning fast onboard DSP Dual Processor Architecture. Delivering low latency audio and freeing up your computer's CPU for bigger and more demanding sessions. Unlock better performance and be more productive.

TRIM:

• Adjust the level of every speaker individually to ensure a balanced soundfield.

SPEAKER DELAY:

• Make sure audio from every speaker arrives at the mix position precisely at the same time.

BASS MANAGEMENT:

• Accurately hear ALL of the bass and low end frequencies in your mix with ORIA's bass management controls, featuring a per channel configurable crossover filter.

8 BAND EQ:

• Deal with unwanted acoustic issues and colouration to ensure a flat and consistent translation of your audio.

HARDWARE FEATURES:

Supports up to 9.1.6 Speaker Setups

2 x 16 Channel Surround Outputs (Analogue & AES)

2 x Stereo Line Outputs (Relay Switched)

2 x Independent Stereo Headphone Outputs

2 x Audient Mic Preamps (Mic / D.I / Line)

2 x ADAT Inputs

Word Clock Input

Word Clock Output

ORIA Motion UI

24 bit / 96kHz

USB 2.0 / USB Type-C

SoundID Reference Measurement Microphone Included

Optional AoIP Card (Dante) for 16 Input channels

SOFTWARE FEATURES:

ORIA Software

Onboard Room Calibration DSP

Per Output EQ

Per Output Delay

Per Output Trim

Per Output Crossover (Bass Management)

Profile Switching - Sonarworks Integrated

Configurable Global Bypass

Immersive Monitoring Control

Input / Output Switching

Master Volume Control

Global Delay (lip sync)

Individual Speaker Solo & Mute

Speaker Group Solo & Mute

Per Channel Metering (pre & post)

Down Mix Cycling - Dolby Atmos Renderer Integrated

Programmable Function Button

iPad Control App
