Ik Multimedia IK Z-TONE Buffer Boost

The Z-TONE Buffer Boost is a powerful preamp/DI pedal that enhances your guitar or bass tone with pro-level clarity, warmth, and control-right from the front of your pedalboard. Developed with the same tone-shaping input circuits as IK Multimedia's acclaimed AXE I/O interface, this ultra-versatile tool brings studio-quality dynamics and flexibility to any live or recording rig. Whether you're taming a long signal chain, adding a touch of analog warmth, or shaping the feel of your instrument, Z-TONE Buffer Boost is built to refine your entire sound path.

At its core, the pedal features a switchable PURE or JFET input stage-offering either ultra-transparent signal or rich harmonic coloration. The variable Z-TONE impedance dial lets you sweep from 1 MOhm down to 2.2 kOhms, dramatically altering your guitar's character and responsiveness, much like switching between amp inputs or passive and active circuits. Add the clean boost circuit to push your pedals or amp harder, or keep your tone crystal clear across long cable runs with the transparent buffer. With multiple output options including XLR, ground lift, and unbalanced 1/4'' jacks, it's ready for any stage, studio, or mixer. Compact, pedalboard-friendly, and made in Italy, Z-TONE Buffer Boost also includes AmpliTube 5 SE for next-level tone sculpting and reamping possibilities.

• Active/Passive Pickup Selector: Optimizes signal path for different pickup types.

• PURE Channel: Delivers clean, transparent tone with no coloration.

• JFET Channel: Adds warmth and subtle harmonic enhancement.

• Z-TONE Impedance Control: Adjusts input load to shape tone and feel of your instrument.

• Signal Buffering: Maintains clarity over long cables and complex pedalboards.

• Adjustable Boost Circuit: Adds volume and drive to hit amps or pedals harder.

• Balanced XLR Output: Connects directly to mixers, PAs, or audio interfaces.

• Unbalanced 1/4'' Output: Alternate output for amp or pedal chain connection.

• Ground Lift Switch: Removes buzz and hum from ground loops.

• True Bypass: Preserves tone when pedal is off.

• Multiple Power Options: Runs on 9V battery, 9V power supply, or 48V phantom power.

• Includes AmpliTube 5 SE Software: Full-featured amp and effects modeling for recording and tone shaping.

• Designed and Made in Italy

GENERAL SPECIFICATIONS:

• Preamp and DI pedal with advanced tone shaping

• Designed and made in Italy

• Ultra compact and pedalboard friendly design

• Powered via 9V battery, 48V phantom power, or 9V pedal power supply

INPUT CONFIGURATION:

• Passive input mode for low output vintage and modern pickups

• Active input mode bypasses unnecessary gain stages for active pickups

TONE SHAPING CHANNELS:

• PURE mode for transparent and accurate preamp response

• JFET mode for Class A input buffer with harmonic enhancement

Z-TONE IMPEDANCE CONTROL:

• Variable impedance from 1 MOhm to 2.2 kOhms

• Adjusts pickup load to influence tone and feel

• Sharp and tight at high impedance

• Thicker and bolder at low impedance

BOOST CIRCUIT:

• Adjustable gain boost

• Enhances volume and drive to push amp or pedals harder

SIGNAL INTEGRITY AND BYPASS:

• Transparent output buffer maintains signal clarity over long chains

• True bypass circuit for complete transparency when disengaged

CONNECTIVITY OPTIONS:

• 1/4 inch Link output for amp or pedalboard

• Balanced XLR output for direct connection to mixers and PAs

• 1/4 inch unbalanced output for additional routing

• Ground lift switch for eliminating hum and noise from ground loops

STUDIO INTEGRATION:

• Simultaneous DI and amp mic recording capability

• Record clean and amp-processed signals in parallel

• Ideal for reamping and post production processing

SOFTWARE BUNDLE:

• Includes AmpliTube 5 SE software

• 77 gear models including amps, cabs, and effects

• Expandable with over 400 gear models from top brands and artists

USE CASES:

• Enhances signal integrity and tone for complex live pedalboard setups

• Records clean and processed tones simultaneously in studio environments

• Flexible for both live performance and home studio use

ADDITIONAL OPTIONS:

• Z-TONE DI for standalone DI box application

• AXE I/O and AXE I/O SOLO for audio interface integration with similar tone shaping features
