Grace Design ROXi

The ROXi is a high-performance Grace Design mic preamp built into rugged pedal chassis. It is designed to inspire new creative possibilities for performing and recording musicians. Think horn players, singers, harmonica shredders, one-mic bluegrass bands, Metal-Polka accordion acts. Now you can tweak and perfect your own microphone sound on stage or in the studio.

This one is bigger and more kitchen sink-y. This starts with a precision rotary switch gain control, which levels up the audio performance, especially in higher gain ranges (ribbon mics welcome). A 2 position high pass filter gives excellent control of problem bass / rumble areas at 75Hz or 150Hz. A 3-band EQ with sweepable mids rounds out the tone shaping. The FX loop can be defeated by a footswitch and has an onboard blend control to run your effects at 100% and adjust wet / dry amount on the preamp. The input is a combi XLR / 1/4″ jack, so it can run as an instrument preamp like its buddy ALiX .

We could keep going, but you get the idea: REX and ROXi are wicked mashups of a mic pre, channel strip and stage preamp. Plop one on your your studio desktop and boom, you have an genuine Grace Design recording channel. Tack one to your pedalboard and you have a Swiss Army knife style stompbox with astonishing audio performance and massive flexibility.

• Mic / Instrument input with 48V phantom power

• Switchable 75Hz or 150Hz High Pass Filter

• 3 Band EQ w/ High, Low and sweepable Mid

• FX loop with a footswitch for FX mute

• FX Mix control

• Variable Boost circuit

• 1/4 Amp output w/ independent level control

• Mute switch

• XLR balanced ISO output

• Universal 100-240 VAC power supply
