Wolff Audio Tutti

The Tutti is a 500 series discrete microphone and instrument preamplifier, created in collaboration between Wolff Audio and Sunset Sound. It is designed as a tribute to Tutti Camarata, an audio innovator and the founder of Sunset Sound. The original preamp, first installed in the Sunset Sound Studio 1 console, was used to record countless legendary sessions. This modern version, developed by Paul Wolff and Paul Camarata, maintains the essence of the classic design while incorporating top-tier components for exceptional audio performance. The inclusion of Cinemag transformers, designed by David Geren, ensures that this preamp stays true to the original's sonic characteristics.

Built for warmth and precision, the Tutti preamp offers key features such as fixed input gain in 10dB steps, adjustable gain trim, switchable mic and Hi-Z instrument input, and phantom power selection without pops. It also boasts custom dual Cinemag nickel I/O transformers, discrete dual 990 op-amps, and a flat frequency response from 10Hz to 60kHz with minimal distortion. With more than 60dB of gain and a clip onset at +28dBu, it delivers outstanding headroom and clarity. Whether used for vocals, instruments, or studio recordings, the Tutti preamp is a true classic that enhances any session with its rich analog character and high-quality craftsmanship.

• Classic Sound, Modern Build " Inspired by the original Sunset Sound Studio 1 preamp, developed with high-quality components.

• Selectable Input Gain " Fixed gain in 10dB steps with an additional adjustable trim of ±6dB.

• Mic & Instrument Compatibility " Switchable between microphone and Hi-Z instrument input.

• Smooth Phantom Power Switching " No unwanted pops when turning phantom power on or off.

• Custom Cinemag Transformers " Designed to preserve warmth and precision in recordings.

• High-Quality Op-Amps " Uses discrete dual 990 op-amps for superior performance.

• Extensive Gain Range " Offers more than 60dB of gain with an output fader ranging from INF to 65dB.

• Minimal Distortion & Phase Shift " Ensures clarity with less than 0.03% distortion and a flat response from 10Hz to 60kHz.

• Signal & Clip Indicators " Green signal indicator and clip onset at +28 dBu.

• Switchable Output Polarity " Provides flexibility in audio signal flow.

• Front-Panel Inputs " Includes XLR mic (150/1500 ohm) and TRS Hi-Z (100k ohm) inputs for easy access.

GENERAL:

• 500 Series discrete microphone and instrument preamplifier

• Designed in collaboration with Sunset Sound

• Inspired by the original Sunset Sound Studio 1 preamp

INPUT & GAIN:

• Fixed input gain selectable in 10dB steps

• Adjustable gain trim: ±6dB continuous

• More than 60dB of total gain

INPUTS & CONNECTIVITY:

• Selectable microphone and Hi-Z instrument input

• Front panel XLR microphone input

• Hi-Z TRS instrument input (100kΩ impedance)

• Microphone input impedance: 150Ω / 1500Ω selectable

TRANSFORMERS & AMPLIFICATION:

• Custom dual Cinemag nickel I/O transformers

• Discrete dual 990 op-amps

PERFORMANCE & FREQUENCY RESPONSE:

• Clip onset at +28 dBu

• Flat frequency response: 10Hz to 60kHz

• Less than 0.03% distortion at 100Hz

• Minimal phase shift within usable response range

CONTROLS & FEATURES:

• Switchable output polarity

• Phantom power selection (no pops when switching)

• Continuous output fader (∞ to +65dB)

• Green signal indicator

POWER CONSUMPTION:

• Draws less than 100mA per rail
