Apogee Symphony I/O MKII Chassis with Thunderbolt

The Symphony I/O MkII Chassis with Thunderbolt offers the foundational power of Apogee's flagship audio interface, providing a modular, expandable platform ideal for professional studios. Designed for users who want to customize their audio workflow from the ground up, this configuration includes the Symphony MkII chassis and Thunderbolt connectivity-but does not come pre-installed with any I/O modules.

This setup is perfect for studios seeking maximum flexibility. With support for up to 32 channels of analog I/O and full integration with macOS via Thunderbolt, it delivers ultra-low latency, pristine AD/DA conversion, and a future-proof design. The intuitive front-panel touchscreen allows easy access to settings and monitoring, making it an excellent hub for high-end recording, mixing, or immersive audio production environments.

• Includes the Symphony Mk II chassis with Thunderbolt connectivity.

• Allows full customization with modular I/O cards (sold separately).

• Features an intuitive front-panel touchscreen for control and monitoring.

• Supports up to 32 channels of analog I/O when fully configured.

• Offers ultra-low latency and superior AD/DA conversion performance.

• Ideal for studios using Mac OS with Thunderbolt connection.

• Ready for immersive audio setups including Dolby Atmos workflows.

• Built in the USA for professional reliability and long-term use.

GENERAL SPECIFICATIONS:

• Product: Apogee Symphony Mk II

• Model: Symphony I O MKII Chassis with Thunderbolt

• Configuration: Chassis only with Thunderbolt connectivity, no I O modules installed

• Display: Intuitive touchscreen interface

• Modularity: Supports up to 32 channels of modular analog I O (via optional I O modules)

• Power: 90 to 240 VAC, 50 to 60 Hz, 150 W

• Build: Designed and built in the USA

CONNECTIVITY:

• Platform: Thunderbolt

• Compatibility: Mac OS 10.10 and above

• Alternate Options Available: Pro Tools Plus and Waves SoundGrid (not included in this configuration)

DIGITAL CONVERSION SPECIFICATIONS (WHEN MODULES INSTALLED):

• AD THD plus N: minus 115 dB at 22 dBu unweighted

• AD Dynamic Range: 122 dB A weighted

• DA THD plus N: minus 119 dB at 21 dBu unweighted

• DA Dynamic Range: 126 dB A weighted

• Frequency Response: 44.1 kHz to 20 kHz plus minus 0.05 dB

HEADPHONE OUTPUT:

• Front Panel Output: 1 stereo quarter inch

• THD plus N: minus 110 dB at 19 dBu into 600 Ohm, minus 101 dB at 14 dBu into 32 Ohm

• Dynamic Range: 121 dB A weighted

• Output Circuitry: Apogee Constant Current Drive

MONITOR CONTROL AND IMMERSIVE AUDIO:

• Thunderbolt Monitor Workflows: Up to 32 speaker outputs

• Immersive Audio Support: Dolby Atmos and Sony 360 Reality Audio

USE CASE:

• Ideal for studios building custom configurations

• Requires user-selected I O modules for audio input and output functionality

SKU:

• SKU : SYM2

• Configuration: Symphony I O MKII chassis with Thunderbolt only, no I O modules included
