RME M-32 Pro DA II Dante

The M-32 DA Pro II and M-32 DA Pro II-D are 32-channel, 192 kHz digital-to-analog converters designed for premium playback in professional studios, immersive audio installations, and live production environments. Featuring fully balanced outputs with per-channel level settings of +13, +19, or +24 dBu, they deliver a remarkable 119.8 dB(A) SNR with THD+N as low as -111 dB, ensuring unmatched clarity and dynamic range.

The Pro II model provides AVB network connectivity with dual redundant ports, while the Pro II-D integrates Dante networking for seamless operation in Dante-based systems, including direct 64-channel recording and playback via Dante Virtual Soundcard (license required). Both units include MADI I/O (coaxial and optional optical SFP), Word Clock, USB remote control, and dual redundant power supplies. A front display with tri-color peak/RMS meters and customizable channel labeling offers clear, instant feedback. With SteadyClock FS clocking, a powerful routing matrix, and robust redundancy, the M-32 DA Pro II series delivers transparent, reliable audio output for critical listening and high-channel-count distribution.

• 32-channel digital-to-analog conversion with ultra-low distortion and high SNR performance.

• MADI I/O (coaxial & optional optical SFP) with seamless redundancy.

• Native Dante networking with dual redundant ports, up to 64 channels at 192 kHz, compatible with Dante Virtual Soundcard.

• Per-channel +24, +19, +13 dBu output level switching for professional studio and live use.

• SteadyClock FS ensures rock-solid clock stability.

• Tri-color illuminated channel labels for quick and clear identification.

• Integrated routing matrix allows any digital input channel to be sent to any analog output.

• Dual redundant internal PSUs for fail-safe operation.

• Front panel, network, USB, MIDI over MADI, and JSON API control options.

• 1U rackmount form factor with magnetic label cover and preset storage.

GENERAL SPECIFICATIONS:

• Model: M-32 DA Pro II-D

• Type: 32 channel digital to analog converter with MADI and Dante

• Form Factor: 1U 19 inch rackmount

• Network Protocol: Dante IP Core with two redundant Gigabit Ethernet ports

• Redundancy: Dual network, dual MADI, dual redundant PSU

CONNECTIVITY:

• 32 analog outputs via 25 pin D-sub up to +24 dBu

• 2 MADI IO coaxial BNC

• 2 MADI IO optical SFP optional multimode or single mode

• 2 RJ45 Dante network ports up to 64 channels

• Word Clock IO BNC

• USB 2.0 for remote control and firmware

• Optional MIDI IO for legacy remote control

ANALOG LINE OUTPUT SPECIFICATIONS:

• Resolution 24 bit

• Output level switchable per channel +24 dBu, +19 dBu, +13 dBu

• DC coupled truly balanced

• Output impedance 200 Ohm balanced, 100 Ohm unbalanced

• SNR at +13 dBu 116.0 dB RMS unweighted, 119.0 dBA

• SNR at +19 dBu 116.3 dB RMS unweighted, 119.3 dBA

• SNR at +24 dBu 116.5 dB RMS unweighted, 119.8 dBA

• Frequency response at 44.1 kHz 0 Hz to 22 kHz

• THD at '1 dBFS less than '113 dB, less than 0.00022 percent

• THD+N at '1 dBFS less than '111 dB, less than 0.00028 percent

• Channel separation greater than 110 dB

FEATURES:

• SteadyClock FS for jitter reduction and clock stability

• Internal single channel routing across all IO

• SyncCheck and Intelligent Clock Control

• MADI Auto Input seamless redundancy

• Tri color backlit channel indicators with peak RMS metering

• Magnetic cover with customizable channel labels

• 2 inch display with control knob

• 15 preset storage with lock and dark mode

• Remote control via HTTP, JSON, MIDI over MADI, optional MIDI

• Impulse response optimization at 88.2 kHz and higher

• Dante Virtual Soundcard support for up to 64 channels recording and playback
