Sennheiser EK 500 G4 (Gw1: 558-608 MHz)

For professional film productions, easily mounted on any kind of camera.

• Professional sound and excellent construction quality

• Easy to use and fast setup time

• Easy and flexible wireless synchronisation between transmitter and receiver via infrared

• Up to 88 MHz bandwidth, up to 32 channels

• Range: up to 100 meters / 330 feet

• Increased RF output power (10/30/50 mW)

• Up to 8 hours of operation time

DIMENSIONS:

Approx. 82 x 64 x 24 mm

COMPANDER:

Sennheiser HDX

THD, TOTAL HARMONIC DISTORTION:

0.9 %

WEIGHT (INCL. BATTERIES):

approx. 130 g

AUDIO OUTPUT:

3.5 mm jack socket: +17 dBu (mono, balanced)

SIGNAL-TO-NOISE RATIO:

Line: 110 dBA, Phones: approx. 90 dBA

SWITCHING BANDWIDTH:

up to 88 MHz

PEAK DEVIATION:

±48 kHz

NOMINAL DEVIATION:

±24 kHz

OPERATING TIME:

Typically 8 h

MODULATION:

Wideband FM

POWER SUPPLY:

2 AA batteries, 1.5 V or BA 2015 accupack

CURRENT CONSUMPTION:

• At nominal voltage: typ. 140 mA

• With receiver switched off: 25 µA

ADJACENT CHANNEL REJECTION:

Typically 65 dB

INTERMODULATION ATTENUATION:

Typically 65 dB

POWERING:

3 V battery / 2.4 V rechargeable battery

RECEIVING FREQUENCY:

• Max. 3520 receiving frequencies

• Adjustable in 25 kHz steps

• 20 frequency banks

• Each with up to 32 factory-preset channels

• No intermodulation

• 6 frequency banks with up to 32 programmable channels

RF SENSITIVITY:
