Obsbot Talent

The OBSBOT Talent Live Streaming Studio is an all-in-one multi-cam live streaming and production device designed to simplify and enhance your live streaming experience. It combines an encoder, switcher, monitor, and recorder into a single device, supporting multiple video inputs including HDMI, USB, and network connections. With features like a touchable screen, ISO recording, video editing tools, and real-time streaming to platforms like YouTube and Twitch, it's ideal for creators seeking a seamless and professional live streaming workflow.

• 5.4" 1920 x 1080 AMOLED Touchscreen

• For OBSBOT Webcam & PTZ Cameras

• 2 x HDMI and 2 x USB-A Inputs

• NDI/SRT/RTMP Streaming Protocols

• Dual-Band WiFi & Bluetooth 5.0 Support

• Up to UHD/DCI 4K Video, ISO Recording

• Ethernet and USB-C Connectivity

• 3.5mm Audio Ports, SD Card Slot

• Horizontal & Vertical Orientations

SCREEN:

• Size: 5.44"

• Type: AMOLED

• Aspect Ratio: 16:9

• Resolution: 1920x1080

• Brightness: 350 nits

• Color Depth: 8-bit

• Contrast Ratio: 6000:1

• Color Gamut: 105% NTSC

• Refresh Rate: 60Hz

• Viewing Angle: All

• PPI: 405

• Touchscreen: Capacitive

• Screen Coating: Anti-fingerprint

VIDEO INPUT:

HDMI: 2x HDMI 2.0 Type-A ports

Resolutions/Frame Rates:

• 4096x2160p/3840x2160p: 23.98/24/25/29.97/30/59.94/60 fps

• 1920x1080p: 23.98/24/25/29.97/30/50/59.94/60 fps

• 1280x720p: 23.98/24/25/29.97/30/50/59.94/60 fps

• 720x576p, 720x480p, 720x480i: Various frame rates

• Color Depth: 8/10/12-bit

• Color Sampling: RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2

USB: 2x USB 3.0 Type-A, 1x USB 3.0 Type-C ports

Resolutions/Frame Rates:

• Single USB-A or USB-C: Up to 1920x1080p, 60fps

• Dual USB-A or USB-A + USB-C: Up to 1920x1080p, various frame rates

• Formats: YUYV, MJPG, NV12

AUDIO INPUT:

• 3.5mm jack: 1x, 2-channel, 48 KHz, 16-bit

• HDMI Port: 2-channel, 48 KHz, 16-bit

• USB Port: 2-channel (microphone only)

• Bluetooth: 2-channel, 48 KHz, 16-bit

• Audio Sources: SRT, RTMP, NDI streams, embedded audio in video files

• Background Music: MP3, M4A, WAV files

VIDEO OUTPUT:

Streaming and Recording:

• Codec: H.264, H.265

• Resolution: Up to 1080p

• Frame Rate: 60/59.94/50/30/29.97/25/24/23.98/15 fps

• Bitrate: Up to 62.0Mbps (NDI HX3), down to 256kbps

• Key Frame Interval: Customizable

• Profile: High profile, Main profile, Baseline profile

• Bitrate Mode: VBR, CBR

USB-C: 1x USB 3.0 Type-C port, DP-OUT, UVC/UAC

• Resolution: 1920x1080, 60fps

• Sampling Format: RGB 4:4:4

AUDIO OUTPUT:

• Streaming and Recording: 2-channel, 16-bit, 48 KHz, aac, 64kbps/96kbps/128kbps

• Headphone Output: 1x 3.5mm jack, 2-channel, 48 KHz, 16-bit

• USB-C and USB-A: 2-channel, 48 KHz, 16-bit/24-bit/32-bit

• Bluetooth: 2-channel, 48 KHz, 16-bit

CONNECTIVITY:

• Ethernet: 1x RJ45 port, 10/100/1000 Mbps

• Wi-Fi: 2.4G/5G, Station and Hotspot modes supported

• Bluetooth: BT 5.0

• Cellular: USB modem supported (not included)

STORAGE:

• Local Storage: 64GB

• SD Card: FAT32 (up to 128GB), NTFS, exFAT

POWER:

• AC Power: 12V/1.5A, Max 15W consumption

• Battery: 2x DC 7.4V (NP-F battery packs, hot swappable)

OPERATING ENVIRONMENT:

• Temperature: -10 to 50C (Operating), -20 to 70C (Storage)

• Humidity: 5% to 90% non-condensing

ADDITIONAL FEATURES:

• PTZ Control, AI Auto Tracking, Chroma Key, Multi-Cam Recording, Live Streaming (YouTube, Twitch, Facebook), ISO Recording, Telestration, Video Overlays

SIZE & WEIGHT:

Size

• 147.2mm x 90mm x 28.5mm

Weight

• With Stand: 402.9g

• Without Stand: 495.2g

WHAT'S IN THE BOX:

• OBSBOT Talent Power Adapter x1

• Mini Stands x 2

• Sun Hood x1

• Thumb Screws x 2
