Audient Nero

Simply hold down a Smart Touchpoint to put it into setup mode, select your routing options and press it again to save.

Inputs As your studio grows it becomes harder to control. Nero enables you to centralise, connect and control all your monitoring needs from your desktop using Nero's array of stereo inputs.

Outputs Reference your mixes on up to three sets of speakers, independently set and match volume for all speakers and audition and assign your sub to any monitor path. Nero also provides one dedicated monitor grade headphone amp and three foldback grade headphone amps, making sure you're ready to take on the loudest of sessions with crystal clear headphone mixes.

Assignable Sub Easily assign a sub to activate when switching to a monitor path of choice but maintain the ability to switch it on and off without losing your saved preset. Nero also lets you audition the sub on any alternative set of speakers without forcing you to assign it permanently

User Defined Dim Set your attenuation using the volume knob

Latching buttons Activate Dim, Mono or Talkback with either a tap (latch) or a tap and hold

Tactile Speaker Select Audition your mixes by quickly switching between monitors

Cue Mix Monitoring Reference what your artist is hearing and fix problems fast

Sum and Difference Use this classic trick to quickly hear your stereo information

Smart Mono Mode Permanently assign a mono speaker without preventing mono functionality on other sources

• 4x Stereo Analogue sources

• 2 x Line Level Inputs

• 1 x Dedicated Cue Mix Input

• 1 x Aux Input (RCA or Mini Jack)

• Optical & Coaxial S/PDIF Inputs

• 3 x Stereo Speaker Outputs

• 1 x Assignable Sub Output

• 4x Headphone Outputs with flexible routing

• Smart Touchpoints for user customisation

• Talkback Input

• Internal Microphone

• External Talkback Input

• Dim, Cut, Mono & Polarity Monitor Controls

BALANCED LINE INPUTS:

NOMINAL INPUT LEVEL: +4dBu

MAX INPUT LEVEL: +18dBu

CMRR: > 50dB

MIC EIN: -128dBu

CMRR: >80dB @ 1kHz

UNBALANCED AUX INPUTS:

NOMINAL INPUT LEVEL: -10dBV

MAXIMUM INPUT LEVEL (minimum trim): +27dBu

TRIM RANGE: ±12dB

DIGITAL INPUTS:

INPUTS: TOSLINK and Coaxial

FORMAT: S/PDIF

SAMPLE RATES: 44.1kHz - 192kHz

BIT DEPTH: up to 24bit

TALKBACK INPUTS:

MAXIMUM IPUT LEVEL: 2dBu

GAIN: 4-44dB

PHANTOM POWER: +48V

SPEAKER OUTPUTS:

MAXIMUM OUTPUT LEVEL: +12dBu

HEADPHONE OUTPUTS:

MINIMUM LOAD: 12.8Ohms

PERFORMANCE:

SPEAKER OUTPUTS:

THD+N: 0.0015% 0dBu 1k input

SNR: 100dBu

CROSSTALK (SPEAKERS): >100dB

FREQUENCY RESPONSE: 20Hz - 22kHz ±0.5dB

ATTENUATION AT MIN VOLUME (SPEAKER OUTPUTS): >110dB

DAC:

THD+N: <0.0017%

DYNAMIC RANGE: 113dB

FREQUENCY RESPONSE: 20Hz - 22kHz ±0.5dB

HEADPHONE OUTPUTS:

THD+N @ 0dBu (output level): 0.009% - 30Ohm

0.009% - 60Ohm

0.008% - 600Ohm

PEAK POWER OUTPUT: 90mW - 30Ohm

56mW - 60Ohm

7.35mW - 600Ohm

CROSSTALK: >62dB

ATTENUATION AT MIN VOLUME: >96dB

POWER SUPPLY: 12VDC Centre Positive DC Adapter - 2Amps

Weight: Unit: 2kg

Dimensions: Unit: 255mm (w) x 75mm (h) x 155mm (d)
