BAE 1073DMP - Desktop Mic Pre

All units come standard with the 'Bootsy Collins' mod which consists of a Jensen DI transformer to create the first 1073 direct box. The 1073DMP features include two DI thrus, phase reverse, 48V for phantom power, a built in PSU for extra portability and the same hand-wired modular design that BAE is known for.

• Built in PSU for extra portability.

• DI in and DI through.

• 48v for phantom power.

• Solid steel chassis.

• Same hand-wired modular design that BAE is known for.

FREQUENCY RESPONSE:

10Hz to -3dB at 55kHz

MIC PRE INPUT IMPEDANCE:

1200 ohms

DI INPUT IMPEDANCE:

150k ohms

OUTPUT IMPEDANCE:

65 ohms

COMMON MODE REJECTION RATIO:

100dB min @ 60Hz

MAXIMUM OUTPUT LEVEL:

+27.4 dBu @ 600

POWER REQUIREMENTS:

115/230 VAC, 28W

GAIN VOLTAGE:

0 to 33.4 Volts

GAIN DB:

0 to 71 dB

EQUIVALENT INPUT NOISE:

-110 dBu; Unweighted 300kHz Bandwidth

WEIGHT:

7.3 LBS/3.31 KG

DIMENSIONS (INCHES):

5.3W x 4L x 11D
